Introduction:This tutorial shows how to configure the HT503 with an Asterisk server without SIP registration. This tutorial is made so you can get the caller ID displayed on your CDR of your PBX server. A simplified HT503 peering scenario is presented on Figure 1.Requirements:. An HT503 with the latest firmware loaded.
An Asterisk PBX Server ( this tutorial is using Elastix as a PBX). Prior to starting the configuration on the HT503, you should make sure that the caller ID is displayed on your analog phone without any intermediate device (PBX, ATA etc). To do so, simply take your phone with a screen that is able to display the caller ID and plug it to the PSTN line. The caller ID is absolutely necessary if you want your server to log your calls and use information related to the caller ID.
Asterisk Pbx Guia De La Configuracion Pdf Gratis
The phone should be able to display the caller ID to witness the outcomes of this tutorial. HT502 peered with Asterisk/Elastix/Trixbox Figure 1: Simplified VoIP network in which the peering is made between the HT503 and Asterisk ServerCaller ID test on your HT503:At first, we have to be sure that the HT503 handles the caller ID correctly; otherwise there will be no need to proceed to the next step.
Asterisk 16 Book
A verification to see if the HT503 handles the caller ID properly is needed. You can verify if the caller ID is properly handled by doing like this:. Open the web interface of your HT503.
Click on the FXO port. Scroll down of the page:. Go to the Caller ID Scheme: Select the Caller ID Scheme that is supported by your phone service provider from the drop down menu. Go to Caller ID Transport Type: Select the method by which the caller ID is transported.
Scroll down of the page to Number of rings. This is the number of times the FXO port will be ringing before having the a VoIP extension ringing or before having the phone on the FXS port ringing if PSTN Ring through FXS is set to yes.
Please set it to a value that is equal or greater than 4. Scroll down of the page to PSTN Ring Thru FXS to Yes, so the phone connected to the FXS port will ring. Click on update. Check if the same Caller ID settings on the FXS port are similar to those on the FXO port. Go to the Basic Settings, and check if the Life Line Mode is set to Auto. Setting the Life Line Mode to Auto will allow the device to parse the Caller ID if the HT503 is on, and automatically be a relay if the device is off. Plug the phone to the FXS port, and do a PSTN call to the HT503.
If you see the caller ID on your phone and the HT503 is on and all the previous parameters are respected, the HT503 handles properly the Caller ID. And now you can move on to the next step.Configuration of your HT503:Now that you are sure that the HT503 is handling the Caller ID correctly, you should be able to do the peering of the HT503 with Elastix and having your CDR fetched with the Caller ID from the PSTN network and from VoIP to PSTN.
As mentioned previously, the peering is without registration.Please follow the steps below so you can configure your HT503 to route a call to an extension that you want to receive the call on. The settings below are either an addition or a change to the configuration that was made previously, so you can go through the Asterisk server to make the call to the FXS port of the HT503. Please make sure you go through all these settings:PageSettingsBasic SettingsUnconditional Call Forward: this option will allow you to forward a PSTN call to any extension that you want in the VoIP network.
You can configure the HT503 to send the call to an extension that is registered in Elastix. Example: your Elastix PBX IP address is 192.168.1.254 and listening on incoming SIP connections on 5060, the FXS port of the HT503 is registered to Elastix and the extension number is 4001. So the Unconditional Call Forward will beAdvanced SettingsLife Line Mode: as explained before this will change the behavior of the HT503 depending on whether it’s powered on or off. If the device is on, then It will handle the Caller ID and can transfer it to the Asterisk server, if not it will act just as a simple relay.
